— A range of silicone conformal coatings, comprehensively enhancing the reliability and safety level of BMS. With the rapid development of new energy vehicles, energy storage systems, and high-end industrial equipment, BMS (Battery Management System) is operating in complex environments such as high humidity, high temperature, salt spray, dust, and electrochemical corrosion for extended periods.
Once the PCB board becomes damp, experiences creepage, or is corroded, it will directly affect the safety and lifespan of the battery system.
Therefore, three-proofing coating (moisture-proof, mold-proof, and salt spray-proof) has become a standard process for BMS electronic protection. Silicone three-proofing coating, with its excellent flexibility, electrical insulation, and environmental adaptability, has become the mainstream material choice for BMS coating.
Analysis of core requirements for BMS three-proofing coating In BMS applications, three-proofing coating materials typically need to meet the following requirements simultaneously:
Excellent moisture resistance, salt spray resistance, and chemical corrosion resistance Long-term stable electrical insulation performance Resistance to thermal shock, avoiding coating cracking caused by thermal expansion and contraction Fast surface drying, improving production line efficiency Compliance with UL flame retardant and environmental regulations Reworkability, facilitating maintenance and quality control For different BMS structural designs and process requirements, the following various silicone conformal coatings can provide differentiated solutions.
Recommended product and detailed explanation of application advantages 1️⃣ Coating 9062 silicone conformal coating adhesive
Basic selection of high reliability protection for BMS
A single-component, low-viscosity, environmentally friendly formula with excellent workability, complies with RoHS requirements and forms a dense, flexible protective film, effectively isolating water vapor and corrosive media. Applicable scenarios: PCB areas with high protection requirements and relatively compact structures, such as BMS control boards, sampling boards, and equalization circuits.
View Coating 9060 details 2️⃣ SIPC 1823 silicone conformal coating adhesive quick-drying BMS production line efficiency solution
The single-component silicone adhesive has a low viscosity of approximately 6000 cps, making it suitable for spraying, brushing, and selective coating. The surface drying time is less than 5 minutes, significantly improving production efficiency. It meets UL flame retardant requirements. Applicable scenarios: high-volume BMS production lines, automated coating processes with high requirements for efficiency and coating uniformity.
View SIPC 1823 details 3️⃣ Coating 9060 Silicone conformal coating high-end BMS reworkable conformal coating solution
Three-proofing adhesive, single-component, 100% solid content, environmentally friendly, solvent-free, ultra-low viscosity (480 cps), excellent permeability, contains fluorescent indicator for online detection and quality traceability, Shore A20 hardness, excellent flexibility, reworkable design, friendly for maintenance, recommended coating thickness 40–100 μm, UL flame retardant certification. Applicable scenarios: high-end new energy vehicle BMS, energy storage BMS, applications with high requirements for reliability, maintainability, and quality visualization.
View Coating 9060 details 4️⃣ SIPC 2130 silicone conformal coating adhesive high viscosity thick film conformal coating type BMS protection solution
Single-component, 100% solids, environmentally friendly, with a viscosity of approximately 28,000 cps, suitable for locally thick-film coating on PCB surfaces to form a 1–2 mm thin protective layer, providing enhanced mechanical and environmental protection. Flame retardant rating: UL HB. Applicable scenarios: BMS local high-risk areas, such as high-voltage sampling, power modules, interface solder joints, and other areas requiring enhanced protection.
Viewing the details of SIPC 2130, the conclusion is: providing long-term stable three-proofing protection for BMS. In the BMS system, three-proofing coating is not simply “applying a layer of glue”, but a key process related to the safety, stability, and lifespan of the battery system.
By reasonably selecting silicone conformal coatings of different performance levels, an optimal balance can be achieved between protective performance, production efficiency, and maintainability.
Whether it’s standard protection, rapid mass production, or high-end reworkable solutions, the aforementioned products can provide BMS with reliable, compliant, and sustainable conformal coating solutions.
